20W SAA Certified Wall Adapter
Professional-grade 20W wall adapter with comprehensive safety certifications for global markets.
Technical Specifications
Output Mode: Constant voltage
Input Voltage: AC100-240Vac, 50/60Hz or 220-240Vac, 50/60Hz
Output Range: DC5V-36V, 0.01A-3A, 24W Max
Protections: Short circuit, over current, over voltage
Energy Efficiency: DOE, CEC, ERPII MEPS GEMS
Operating Environment: 0-40℃, 5%-95% RH
Certifications: UL, cUL, FCC, GS, CCC, CQC, KC, PSE, UKCA, SAA, C-tick, RCM, RoHS, CB
Regional Specifications
| Country |
Max. Watt |
Voltage Range |
Current Range |
Safety Standard |
| US |
24W |
DC5-36V |
0.01A-3.0A |
EN62368/UL 1310 |
| EU |
24W |
DC5-36V |
0.01A-3.0A |
EN62368 |
| UK |
24W |
DC5-36V |
0.01A-3.0A |
EN62368 |
| AU |
24W |
DC5-36V |
0.01A-3.0A |
EN62368 |
| KR |
24W |
DC5-36V |
0.01A-3.0A |
EN62368 |
| JP |
24W |
DC5-36V |
0.01A-3.0A |
EN62368 |
| CN |
24W |
DC5-36V |
0.01A-3.0A |
CCC-GB 4943.1-2022/CQC-GB 4343.1-2018;GB/T 4343.2-2020 |
Key Features
- Single channel constant voltage power supply
- 100% full load burn-in testing
- Passes LPS (limited power source) requirements
- 3-year comprehensive warranty
- Class II power design (without earth pin)
- Compact size with fully enclosed PC plastic case
- Fast startup time: <3 seconds
- High energy efficiency: DOE/CEC/ErP/MEPS/NRcan Level VI
- Automatic safety protections for over current, over load, and short circuit
FQA
Q1: What certifications does this 20W wall adapter have?
A: SAA, UL, cUL, FCC, GS, CCC, KC, PSE, UKCA, RCM, RoHS, CB and more, suitable for global markets.
Q2: What are the output parameters?
A: Single‑channel constant voltage, DC 5‑36V, 0.01‑3A, max 24W.
Q3: What safety protections are included?
A: Short‑circuit, over‑current, over‑voltage and overload protection. Pass LPS requirement, 100% full‑load burn‑in tested.
Q4: What plugs and DC connectors can I choose?
A: AC plugs for US, EU, UK, AU, KR, JP, CN, Brazil, India etc. Multiple DC connectors in stock, custom options supported.
Q5: What applications and environment are suitable?
A: For LED strips, amplifiers, routers, audio‑video devices etc. Indoor‑use only, 0‑40℃, 5%‑95%RH, non‑waterproof.
Q6: Do you support OEM & ODM?
A: Yes, custom labels, packaging, case and connectors are available.
Q7: How long is the warranty?
A: 3‑year comprehensive warranty.
Why choose us?
Full Global Certifications
20W wall‑mount adapter with SAA, UL, FCC, UKCA, CCC and other global certifications, qualified for worldwide sales.
Multi‑fold Safety Design
Built‑in short‑circuit, over‑current, over‑voltage & overload protection. Meets LPS standard. Class II double‑insulation without earth pin. Every unit passes 100% full‑load burn‑in test.
High‑efficiency & Compact Build
Single‑channel constant‑voltage output. Comply with Level VI energy‑efficiency norms. Startup＜3s, fully‑enclosed PC housing for indoor application.
Wide Plug & Connector Options
Support multi‑country AC plugs and various DC tips. Custom connectors available for diverse device matching.
Warranty & Custom Service
3‑year comprehensive warranty. Support OEM / ODM for custom labels, packaging and housing.
Compatible AC Plugs
US, EU, UK, AU, Korea, Japan, China, Brazil, India, Argentina and other regional standards
Available DC Connectors
- 5.5*2.1mm
- 5.5*2.5mm
- 4.0*1.7mm
- 3.5*1.35mm
- 2.5*0.7mm
- XLR
- Other customizable options
Applications
Ideal for electric grill ovens, LED strips, audio amplifiers, wireless routers, and audio/video power supplies.
Not waterproof - indoor use only.
Customization Services
We offer comprehensive OEM and ODM services with custom labeling, packaging, and case design options available to meet your specific requirements.
