60W High Efficiency Wall Plug Adapter
High-performance 60W wall plug adapter designed for reliable power supply across various applications.
Technical Specifications
Output Mode: Constant voltage modes
Input: AC100-240Vac, 50/60Hz or 220-240Vac, 50/60Hz
Output: DC5V-36V, 0.01A-3A, 24W Max
Protections: Short circuit, over current, over voltage
Energy Efficiency: DOE, CEC, ERPII MEPS GEMS
Working Environment: 0-40℃, 5%-95% RH
Certifications: UL, cUL, FCC, GS, CCC, CQC, KC, PSE, UKCA, SAA, C-tick, RCM, RoHS, CB
Regional Specifications
| Country |
Max. Watt |
Voltage Range |
Current Range |
Safety Standard |
| US |
65W |
DC5-36V |
0.01A-5.0A |
EN62368/UL 1310 |
| EU |
65W |
DC5-36V |
0.01A-5.0A |
EN62368 |
| UK |
65W |
DC5-36V |
0.01A-5.0A |
EN62368 |
| AU |
65W |
DC5-36V |
0.01A-5.0A |
EN62368 |
| KR |
65W |
DC5-36V |
0.01A-5.0A |
EN62368 |
| JP |
65W |
DC5-36V |
0.01A-5.0A |
EN62368 |
| CN |
65W |
DC5-36V |
0.01A-5.0A |
CCC-GB 4943.1-2022/CQC-GB 4343.1-2018;GB/T 4343.2-2020 |
Key Features
- Single channel & Constant Voltage power supply
- 100% Full load burn-in test
- Pass LPS (limited power source)
- 3 Years Warranty
- Class II power (without earth pin)
- Compact size, fully enclosed PC plastic case
- Starting time: <3 seconds
- Energy Efficiency: DOE/CEC/ErP/MEPS/NRcan Level VI
- Safety automatic protections for over current, over load and short circuit
FQA
Q1: What is the output specification of this adapter? A: 60W high power single channel constant voltage DC5V-36V 0.01A-3A max 65W for regional markets
Q2: What certifications does it have? A: UL cUL FCC GS CCC KC PSE UKCA SAA RCM RoHS CB and other global certifications
Q3: What safety features are included? A: Automatic protections against short circuit over current over voltage and overload passes LPS requirements Class II design no earth pin
Q4: Which plugs and DC connectors are available? A: Compatible with US EU UK AU JP CN Brazil India and other regional AC plugs various DC plugs 5.5*2.1mm etc are optional customization supported
Q5: What are the application scenarios and usage conditions? A: Suitable for electric grill ovens LED strips amplifiers routers etc indoor use only non waterproof operating temperature 0-40℃ humidity 5%-95% RH
Q6: What about warranty and customization services? A: 3-year comprehensive warranty OEM/ODM services are available for custom labels packaging and case design
Why choose us?
High-Efficiency & Reliable Performance 60W high-power output meets DOE/CEC/ErP Level VI efficiency standards fast startup <3s 100% full load burn-in tested for stable power supply
Global Certifications for Wide Application Certified with UL FCC UKCA CCC KC PSE and more compatible with plugs for US EU UK AU JP CN and other regions
Comprehensive Safety Assurance Built-in short circuit over current over voltage and overload protections passes LPS requirements Class II design no earth pin for safe use
Versatile Compatibility & Customization Compatible with various DC plugs customizable suitable for electric grill ovens LED strips amplifiers and more supports OEM/ODM with custom labels packaging and case
Trusted After-Sales Support 3-year comprehensive warranty compact fully enclosed PC plastic case for long-term indoor use
Compatible AC Plugs
US, EU, UK, AU, Korea, Japan, China, Brazil, India, Argentina and others
Available DC Plugs
5.5*2.1/5.5*2.5/4.0*1.7/3.5*1.35/2.5*0.7/XLR/
Applications
The AC adapter is suitable for electric grill oven, LED strips, audio amplifiers, wireless routers, audio and video power supplies, etc.
Not waterproof, indoor use only.
Customization Services
We provide OEM and ODM services with custom labeling, packaging, and case options available.
